Performance Bulletin

Masters 247 — Yamaha F300XSB2 · Single

Official Yamaha test data, normalized to the Sportsman sheet.
Mercury V10 Verado 350 · Single Yamaha F300XSB2 · Single Yamaha F350XSA2 · Single
Powered by
Performance Test
113 Sportsman Way · Summerville, SC 29483 · 843.376.2628
Masters 247
Single Yamaha F300XSB2 · 300 hp total
Tested 28 Jun 2023
2 people aboard · 4,591 lbs as tested
Sheet SPT-247-F300XSB2SINGLE
Top speed
50.9 mph
@ 5,800 rpm
Best cruise
3.50 mpg
29.6 mph @ 3,500 rpm
Cruise range
207 mi
on 59 usable gal
Time to plane
3.50 s
hole shot
0–30 mph
7.70 s
0–20 mph: —
Performance Data
RPM
MPH
GPH
MPG
Range
1,000
5.3
1.4
3.79
224
1,500
7.3
2.3
3.17
187
2,000
8.5
3.9
2.18
129
2,500
11.1
5.5
2.02
119
3,000
17.5
6.6
2.65
156
3,500
29.6
8.5
3.50
207
4,000
34.8
11.8
2.96
175
4,500
39.7
15.3
2.59
153
5,000
44.2
20.2
2.19
129
5,500
49.2
25.9
1.90
112
5,800
50.9
26.4
1.93
114
Range: MPG × 59 usable gal (90% of a 65 gal tank), no reserve held back — same rule on every Sportsman sheet.
Performance Curve
0 8 15 23 30 38 45 53 60 1.90 2.14 2.38 2.61 2.85 3.09 3.32 3.56 3.80 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 5800 MPH / GPH MPG Engine speed (rpm)
GPH MPH MPG
Time to plane
3.50 s
0–20 mph
—
0–30 mph
7.70 s
Engine
Horsepower300 hp
InductionEFI/VCT/DOHC
Displacement4.2L
Weight (est.)611 lbs each
Gear ratio1.75:1
Propellers & Mounting
SeriesSaltwater Series II
Diameter × pitch15-1/4 x 18
Part number6CE-45934-20-00
MaterialStainless Steel
Mounting hole#1
Ventilation plate1.75" Above Boat Bottom
Test Conditions
Test date28 Jun 2023
Aboard2 people
Weight as tested4,591 lbs
Fuel at test35 gal
Air / water89° F / 85° F
Wind / sea10–15 mph
Elevation0 ft
Comments. Test weight includes 35 gallons of fuel, 5 batteries, 10" hydraulic jack plate, twin Power Pole shallow water anchors, 36 volt bow mounted trolling motor, safety and test equipment.
Approximate and provided as a guideline only. Your boat's performance will vary with weight, sea state, wind, temperature, elevation, bottom condition, options and operator. Confirm figures for your specific boat and engine package with your Sportsman dealer before purchase.
Source
Yamaha Performance Bulletin PB_SPT_Masters 247_F300XSB2_6-28-2023_BAY
sportsmanboatsmfg.com
The normalization

What each brand calls it, and what we print

An em dash means the brand does not measure it. Range is computed on the Sportsman rule, both brands.
Field
Yamaha bulletin
Sportsman sheet
Mercury bulletin
Configuration
Configuration: Twin / Triple
Engines · N × model
Number of Engines
Rig detail
Mounting hole, ventilation plate height
Mounting & setback
Mounting bolt hole, engine height, setback
Propeller
Series, diameter × pitch, part #
Series, pitch, blades, material
Mercury name, pitch, blades, material
Hole shot
Time to Plane
Time to plane
not measured
Acceleration
0–30 mph
0–20 mph and 0–30 mph
0–20 mph and 0–30 mph
Range
not published
computed: MPG × usable fuel
published miles per rpm
Crew
Number of People
Aboard
Test conductor + n
Sea state
not recorded
Wind / sea
Wind velocity, sea state
Top speed
highest rpm row
top row of the curve
stated separately from the table

Source bulletin: original Yamaha PDF
